Are you going on a hunt for the best mountain ebike, but don't know which brake type is best for you? There's no need to worry, because we have brought a detailed guide about disc brakes vs rim brakes to help riders know which works best for their commuting requirements.

Don't neglect the importance of instantly stopping brakes to purchase a ride that can ensure your safety, no matter what the weather conditions are and on which tracks you are going to commute. That's why you should always make sure to understand the working mechanism of famous disc brakes or rim brakes and their efficiency level.

It will help you to invest your hard-earned money in a reliable product that can provide instant braking response if something suddenly appears in front of your ride at whatever speed or track you are travelling.

What are Rim Brakes & Their Types?

Rim brakes are typical brakes that come with normal bicycles that we used to ride since our childhood. It usually comes with two arms mounted on each side of the rim, supported by a single bolt attached to the fork.

When a rider squeezes the brake levers mounted on the handlebar, the wire attached to the arms with rubber pads clamps the rim and converts the kinetic energy into heat by producing friction. These brakes work best under normal conditions but drop efficiency when the rim moves through wet roads and muddy tracks.

In the tug of war between rim brakes vs disc brakes, these brakes are less efficient and provide less stopping power in difficult conditions like off-roading tracks. Rim brakes usually come in two forms, which are mentioned below.

bicycle rim brakes

1. Calipers

It is the most widely used type as it consists of two arms on both sides of the rim connected with a single dual-pivot arch bolt placed above the tyre on the suspension fork. These kinds of electric bike brakes work by squeezing the rim with both pads, depending on the force applied by the rider on the lever.

2. V-Brakes

As its name suggests, this brake type consists of two long arms attached to both sides of the fork upon the rim and connected by a single wire leading to the brake levers mounted on the handlebar. These provide more tyre clearance and stopping power than the clippers due to heavy-duty rubber pads attached to them.

What are Disc Brakes & Their Types?

Disc brakes, as their name suggests, come with a circular metal disc (rotor) attached to the wheel hub and brake calliper mounted near the wheel. The whole mechanism is isolated from the rim because it depends on the wheel hub and dissipates less heat than rim brakes to provide instant stopping on every kind of terrain.

All modern and powerful electric bikes like ENGWE Engine X come with front and rear disc brakes to provide safe riding and instant response to the riders. Which means buying an electric cycle with disc brakes is necessary to ensure your and others' safety while commuting.

There are commonly two types of bicycle disc brakes, as mentioned below and used by electric bike manufacturers like ENGWE. Read them to further know the difference between disc brakes versus rim brakes to bring home a perfect vehicle in every sphere of riding.

cycle disc brake

1. Mechanical

Mechanical disk brakes bike come with a single piston or arm that is connected to the hub of the wheel. It works when the rider squeezes the cable, and then it presses the pads against the rotor to decrease the speed of the vehicle according to the force applied to it.

2. Hydraulic

Hydraulic disc brakes are almost the same in components as the mechanical disc brakes, but with a little difference in working. When a rider squeezes the brake levers mounted on the handlebar, it pushes fluid through a sealed hose that evenly moves pistons on both sides of the rotor to provide an instant stopping response.

Pros and Cons of Disc Brakes vs Rim Brakes

We have consulted with seasoned bikers and conducted deep research by testing both bike disc brakes and rim brakes under different weather conditions and on different terrains. To find out the real-time pros and cons of buying an electric bike that comes with any of the two types of braking systems.

Feel free to rely on these findings because we have conducted the tests under rigorous conditions to get a fair overview of the stopping power and other factors of both brake types.

  Disc Brakes Rim Brakes
Pros Provides consistent braking power up to a speed of 45 Km/h. The lever feels light enough even to press using a single finger.
Handles long descents without reducing the braking power. No danger of the rotor getting damaged on prolonged riding because there's no rotor.
Doesn't need regular maintenance. Fits every frame, even vintage ones, easily.
No wear and tear because brake pads don't clamp the rim during braking. Cheap to replace.
Cons Levers feel a little heavy in the case of mechanical disc brakes. Doesn't provide consistent braking above a speed of 25 Km/h.
Prolonged dragging can damage the rotor. Compromises the braking response when it gets too hot.
Old frames can't be retrofitted with disc brakes easily. Needs regular maintenance.
In case of replacement, the changing costs are high. Gets worn out very easily.

A Detailed Comparison: Disc Brakes vs Rim Brakes

To clear the air for you to decide which one is efficient in performing either disc brakes or rim brakes, we have formed a detailed comparison table for you to know the major differences between the two types.

  Disc Brakes Rim Brakes
Heat Dissipation The chances of the brake fading away are less due to rapid heat dissipation The chances of the brake fading away are high due to slow heat dissipation
Maintenance Requirements Doesn't need regular maintenance Needs regular maintenance
Wear & Tear Not so often More often
Charging Costs High Low

Which One is Better at Stopping the Bike?

Electric bikes with rim brakes are less effective and responsive at stopping the ride due to less efficient brake pads and the overall braking system. This means it compromises the braking power in rough weather conditions, especially when it is raining or you are passing through a muddy track.

On the other hand, electric cycles with disc brakes, either mechanical or hydraulic, are more effective and responsive at stopping the ride instantly due to the piston connected to the hub of the wheel. Its performance doesn't get affected under any kind of weather or track conditions, and it provides consistent stopping power.

So the winner of disc brakes vs rim brakes is clearly the cycle disk brake, and it would be your reliable partner across the tracks.

disc brakes vs rim brakes

ENGWE's Instantly Stopping Electric Bikes with Disc Brakes

We have shortlisted the best-performing and instantly stopping electric bikes of ENGWE for you. To scroll and bring home an efficient ride that can keep you safe from getting into any accident due to a less efficient braking system.

1. ENGWE MapFour N1 Air

The ENGWE MapFour N1 Air is a lightweight carbon fiber city e-bike, engineered for smooth and efficient urban commuting. Designed with both style and performance in mind, it features 160mm front and rear mechanical disc brakes, delivering powerful and reliable stopping power in all weather conditions. Whether navigating busy streets or making quick stops at intersections, the N1 Air offers riders maximum control and confidence. Its streamlined frame, responsive ride feel, and premium materials make it an ideal choice for daily city travel, combining advanced technology with everyday practicality.

engwe mapfour n1 air carbon ebike with mechanical disc brakes

2. ENGWE M20

The ENGWE M20 is a rugged electric bike built for adventure and versatility. Equipped with powerful 160mm front and rear mechanical disc brakes, it ensures strong, responsive braking on any terrain. Its 20 x 4.0-inch fat tires provide excellent grip, stability, and shock absorption, making it ideal for sand, snow, or rough trails. The full suspension system further enhances comfort and control, smoothing out bumps and delivering a confident ride even on challenging surfaces. With its bold design and durable components, the M20 is perfect for riders who demand performance, style, and off-road capability in every journey.

engwe m20 electric fat bike with mechanical disc brakes

3. ENGWE L20 3.0 Boost

The ENGWE L20 3.0 Boost is a powerful and compact folding e-bike designed for city and adventure riders. It features 180mm front and rear hydraulic disc brakes for superior stopping power and precision control. The full suspension system ensures a smooth ride over bumps and rough streets, while the advanced torque sensor delivers a natural and responsive pedaling experience. Its compact, foldable frame makes storage and transport effortless, perfect for urban living. With 8A fast charging, the L20 3.0 Boost quickly gets you back on the road, combining high performance, comfort, and ultimate convenience in one sleek package.

engwe l20 3.0 boost folding electric biek with hydraulic disc brakes

4. ENGWE Engine Pro 2.0

The ENGWE Engine Pro 2.0 is a powerful and versatile folding e-bike built for both city streets and off-road trails. It features 160mm hydraulic disc brakes for smooth, reliable stopping power, even at high speeds. The 20x4.0" fat tires offer outstanding traction and stability across sand, snow, and rough terrain. With a strong 75N·m motor torque, the Engine Pro 2.0 delivers impressive acceleration and climbing ability. Its foldable frame design adds unmatched convenience for storage and transport, making it ideal for commuters and adventure seekers alike. This e-bike perfectly balances power, comfort, and portability.

engwe engine pro 2.0 foldable electric bike with hydraulic disc brakes

Final Thoughts

When searching for what to look for in an electric bike to invest in the right ride, make sure to add a responsive braking system to the list to purchase a safe vehicle. Keep the difference of disc brakes vs rim brakes in your mind to only buy a ride that can provide instant stopping response on all terrains to ride anywhere you want without doubting the capabilities of your vehicle.
